Fall 2025 – CS6601 – Trail Isolation!

Instructor: Dr. Thomas Ploetz

Deadline: Monday, September 22nd, 7:59 am EDT

Released: Monday, September 8th, 8:00 am EDT

• Discussion is encouraged on Ed as part of the Q/A. However, all assignments should be done individually.
• Plagiarism is a serious offense. You are responsible for completing your own work. You are not allowed to copy and paste, or paraphrase, or submit materials created or published by others, as if you created the materials. All materials submitted must be your own.
• All incidents of suspected dishonesty, plagiarism, or violations of the Georgia Tech Honor Code will be subject to the institute’s Academic Integrity procedures. If we observe any (even small) similarities/plagiarisms detected by Gradescope or our TAs, WE WILL DIRECTLY REPORT ALL CASES TO OSI, which may, unfortunately, lead to a very harsh outcome. Consequences can be severe, e.g., academic probation or dismissal, grade penalties, a 0 grade for assignments concerned, and prohibition from withdrawing from the class.

Assignment Instructions

Assignment Description

The goals of this assignment are as follows:

1. Verify student understanding of foundational adversarial game search algorithms introduced in lecture. (Minimax)
2. Explore improved adversarial search algorithms that build upon the foundational adversarial search algorithms. (AlphaBeta)

Your task is to create an AI that can play and win a game of Trail Isolation. Your AI will be tested against several pre-baked AIs. You will implement your AI in Python 3.9, using our provided code as a starting point.

In case we haven’t got this into your heads enough: start early!!! It is entirely possible, and probably likely, that a large part of your next 2 weeks will be devoted to this assignment, but we hope that it is worth it and you will really enjoy it!

Good luck!

About the Game

Trail Isolation rules

• Pieces & board: Two players, one queen each, on an (N x N) grid (board size per isolation.py).
• Queen movement: On your turn, move your queen like a chess queen: any number of open squares horizontally, vertically, or diagonally, without jumping over blocked or occupied squares.
• Permanent block: After you move, the square you moved from becomes permanently blocked for the rest of the game.
• Temporary “trail” block: All intermediate squares your queen traversed during that move (the path squares between origin and destination) become temporarily unavailable for exactly one opponent turn.
  • These trail squares are unavailable to your opponent during the opponent’s immediate turn (can’t move onto or through them).
  • After the opponent completes their move, those trail squares automatically revert to open.
• Destination: Your queen occupies the destination square (as usual).
• No passing: If a player has no legal move, that player loses.
• Setup: Starting placement and board initialization are randomized and handled by the provided code.

Example:
If you move from  to  along the row, then:

•  becomes permanently blocked.
•  and  are the trail and are temporarily blocked for the opponent’s next turn only.
•  is your queen’s new position.

Table of contents

0. Grading & Submission Policies
1. Additional Helper Files
2. About the Game
3. Assignment contents
4. Exporting the notebook
5. Coding time!
6. Section2a checkpoint!
7. Section2b checkpoint!
8. Section2c checkpoint!
9. Bot fight!)

Grading & Submission Policies

The grade you receive for the assignment will be determined as follows:

As you can see from the table there are three autograded sections, each having the following submission frequency restrictions:

• Section 2a – 1 submission per 30 minutes.
• Section 2b – 6 submissions per 360 minutes.
• Section 2c – 6 submissions per 360 minutes.

Additional Helper Files

While you’ll only have to edit notebook.ipynb and submit the exported submission.py, there are a number of notable files:

1. isolation.py: Includes the Board class and a function for printing out a game as text. Do NOT change contents of this file. We have the same file on the server’s side, so any changes will not be accounted for.
2. notebook.ipynb: Where you’ll implement the required methods for your agents.
3. player_submission_tests.py: Sample tests to validate your agents locally.
4. test_players.py: Contains 2 player types for you to test agents locally:
   • RandomPlayer – chooses a valid move randomly from among the available valid moves
   • HumanPlayer – allows YOU to play against the AI in terminal (else use InteractiveGame in jupyter)

Additionally, we’ve included a number of local unit tests to help you test your player and evaluation function as well as to give you an idea of how the classes are used.

Setup Verification

First, let’s make sure you have installed the correct versions of all of the libraries. To install all the libraries, make sure you ran pip install -r requirements.txt in your Conda environment.

Simply run the cell below. You can click on the cell and press ⇧↩ (Shift + Enter) to run it. If you see any warning/error messages, please make sure you have followed the installation instructions in the README. In case you can’t resolve them please check out Edstem thread dedicated to “Assignment 2”.

About the Game

The rules of Trail Isolation are a variation of the original Isolation game. In the original form of the game there are two players, each with their own game piece, and an (N x N) grid of squares. At the beginning of the game, the first player places their piece on any square. The second player follows suit, and places their piece on any one of the available squares. From that point on, the players alternate turns moving their piece like a queen in chess (any number of open squares vertically, horizontally, or diagonally).

In standard Isolation, after the piece is moved, the square that was previously occupied is blocked permanently, and cannot be used for the remainder of the game. The first player who is unable to move their queen loses.

In this variant called Trail Isolation, queens still move like chess queens, but there is an additional twist:

• The square the queen moved from is blocked permanently (same as standard Isolation).
• The squares the queen passed through during the move (the trail) become temporarily blocked for the opponent’s next turn only.
• After the opponent completes their move, those trail squares automatically open back up.

This means that each move leaves behind a trail that briefly limits the opponent’s options, introducing new strategic considerations.

For clarity, examine the scenario below:

Below is a depiction of the empty starting board position.

Q1 places their queen on the board, and Q2 follows suit. At this position, Q1 has many potential future moves (shown in light blue).

Q1 decides to move three spaces to the right. The square behind (black) becomes permanently blocked, while the intermediate squares (purple) form a trail that is blocked for Q2’s next turn only. The orange shows open spots available to Q2 this turn.

Q2 then moves diagonally up-left. Their starting square becomes permanently blocked (black), and their path squares form a temporary trail (purple). Meanwhile, Q1’s earlier trail is now cleared and those squares are again open.

After several turns, the board fills with permanent blocks. In this example, Q2 has no available moves left, so Q1 wins.

For more clarity, you can try playing the game against the Random Player or against yourself using the interactive tool below

One other thing you can do is simulate a game between two players and replay it.

Run the next cell, click inside the text input box right above the slider and press Up or Down.

Assignment contents

In this assignment you will need to implement evaluation functions and game playing methods. Your goal is to implement the following parts of the notebook:

1. Evaluation functions (OpenMoveEvalFn and CustomEvalFn if you wish to use the latter)
2. The minimax algorithm (minimax)
3. Alpha-beta pruning (alphabeta)
4. Adjust the move() according to section you are trying to work on.

Evaluation Functions

These functions will inform the value judgements your AI will make when choosing moves. There are 2 classes:

• OpenMoveEvalFn – Returns the number of available moves open for your player minus the number of moves available for opponent player. All baseline tests will use this function. This is mandatory
• CustomEvalFn – You are encouraged to create your own evaluation function here.

Notes on these classes

1. You may write additional code within each class. However, we will only be invoking the score() function. You may not change the signature of this function.
2. When writing additional code please try not to copy the existing cells since they contain #export comments that is used for converting the notebook to submission.py file.

CustomPlayer

This is the meat of the assignment. A few notes about the class:

• You are permitted to change the default values within the function signatures provided. In fact, when you have your custom evaluation function, you are encouraged to change the default values for __init__ to use the new eval function.
• You are free change the contents of each of the provided methods. When you are ready with alphabeta(), for example, you should update move() to use that function instead.
• You are free to add more methods to the class.
• You may not create additional external functions and classes that are referenced from within this class.

Your agent will have a limited amount of time to act each turn (1 second). We will call these functions directly so don’t modify the function names and their parameter order.

We have divided the tests into three sections (mentioned in details in next grading section below), each with their own submission limit.

These are the bare minimum requirements for your AI, and the rest is up to you. You will be scored according to how well your AI performs against some baseline AIs that we provide (see Grading). If you want to improve over the base performance, here are a few suggestions:

• Use partition techniques.
• Store the evaluation scores for past moves.
• Modify your evaluation function to account for “killer moves”.
• Optimize functions that are called often.
• Order nodes to maximize pruning.

We will provide you checkpoints and instructions below once you are ready to submit for each of these sections.

Exporting the notebook

In order to do get your submission file ready you will need to make sure have saved your notebook and run:

Once execution is complete open autogenerated submission.py and verify that it contains all of the imports, functions and classes you are required to implement. Only then you can proceed to the Gradescope for submission.

Do NOT erase the #export at the top of any cells as it is used by notebook2script.py to extract cells for submission.

Coding time!

Importing External Modules

If you have discussed this assignment at a whiteboard level, got help from an Ed discussion or have used external resources (not provided by the instructors) that you may want to cite, please do so in the cell below as a python comment! (no need to cite python or included packages documentation)

OpenMoveEvalFn

• This is where you write your evaluation function to evaluate the state of the board.
• The test cases below the code are expected to pass locally before you make a submission.
• Hints: Remember when calling the below helpful methods that you do need to inform both methods of who your player is (consult those methods’ docstrings for more information).

Here are a couple methods you might find useful to implement OpenMoveEvalFn():

About the local test above

You should look at the test in player_submission_tests.py to verify that your evaluation function is correct. If you want to edit the test (which you most definitely can), then edit the source code back in player_submission_tests.py.

CustomPlayer

• CustomPlayer is the player object that will be used to play the game of isolation.
• The move() method will be used to pass over to you the current state of the game board.
• The content of the move() method will be changed by you according to the section you are attempting to pass. While you can use Iterative Deepening & Alpha-Beta (ID+AB) to beat our agents in all of the sections, going directly for ID+AB is error prone. As such, we highly recommend you to start with MiniMax (MM), then implement Alpha-Beta (AB), and only then go for ID+AB.
• By default, right now move() calls minimax() as you can see below.
• You are not allowed to modify the function signatures or class signatures we provide. However, in case you want to have an additonal parameter you can do it at the very end of parameter list (see examples below). However, it must have a default value and you shouldn’t expect it to be passed on the server-side (i.e. Gradescope). Thus, Gradescope will be using the default value.

Originally:

def move(self, game, time_left):
    ...

Adding a new argument with default parameter.

def move(self, game, time_left, new_parameter=default_value):
    ...

Don’t do this, you will get an error in the auto-grader and lose your submission:

def move(self, game, time_left, new_parameter):
    ...

def move(self, new_parameter, game, time_left):
    ...

Minimax

• This is where you will implement the minimax algorithm. The final output of your minimax should come from this method and this is the only method that Gradescope will call when testing minimax.
• With MM implemented you are expected to pass: Defeat a Random Player >=90% of the time.
• Useful functions: The useful methods will probably all come from isolation.py. A couple of particularly interesting ones could be forecast_move() and your score() method from OpenMoveEvalFn. Remember the double question mark trick from Assignment 0 if you feel you are flipping between files too much!

Recommended (Approved) Resources

• Canvas Game Playing Modules
• Course AIMA Textbook 4th Edition, Section 5.1 through 5.2

Section 2a Checkpoint

Now it’s a good time to submit for Section2a – See Exporting the notebook

In case you want to submit please uncomment and run the cell below.

Your code will be generated in the folder named section2a, please upload submission.py file to Gradescope

AlphaBeta

• This is where you will implement the alphabeta algorithm. The final output of your alphabeta should come from this method.
• With A/B implemented you are expected to pass: Minimax level 2 >= 70% of the time
• Useful functions: The useful methods will probably all come from isolation.py. A couple of particularly interesting ones could be forecast_move() and your score() method from OpenMoveEvalFn. Remember the double question mark trick from Assignment 0 if you feel you are flipping between files too much!

Recommended (Approved) Resources

• Canvas Game Playing Modules
• Course AIMA Textbook 4th Edition, Section 5.3

About the lack of a local test above

Notice that we do not have any code here. We want you to learn to write your own test cases, so feel free to get creative! You can always create the test in player_submission_tests.py and then run it over here in a manner identical to how local tests have been run so far.

IMPORTANT

Now remember that the server (i.e. Gradescope) uses move() to interface with your code. So now you will need to update the move() method (which you saw earlier in the CustomPlayer class) to call alphabeta() so as to return the best move.

Section 2b Checkpoint

Now it’s a good time to submit for Section2b – See Exporting the notebook

In case you want to submit please uncomment and run the cell below.

Your code will be generated in the folder named section2b. Please upload submission.py file to Gradescope

That does not cover all 100 points though!

• You’re right, and that’s on purpose. Each of the bullets below try to walk you through how you may want to think about beating the remaining agents.
  • First up is the alphabeta agent. Vanilla alphabeta (that is, alphabeta with no optimization) may not do so well against this agent. However, any agent that searches deeper with the same algorithm probably has a bigger advantage. You may learn about a method that allows your algorithm to search in such a way that you can find the maximum search depth without running out of time. This will probably come up in class or you can read through the book to find out what you are looking for.
  • Next to beat is the agent with iterative deepening. This one is a little harder to think about, given that you may have used all the tools that you may think of to try a make a “better” agent. But you may have just implemented the evaluation function that was discussed in class. Maybe we can do better – like checking for winning moves and prioritizing those! Or if you are feeling really creative, you can always try editing the CustomEvalFn below this cell and come up with an awesome idea of your own.
  • Now to Peter’s agent with the secret evaluation function. Here we have nothing to tell you. Use everything in your toolbox and within the class rules to defeat it. This is by far the hardest 5 points to get! Good luck and have fun!
• Remember that you may want to edit the methods in the cell with the CustomPlayer class to try and implement some of the above. You are certainly free to as long as you adhere to the general rules about editing provided code (which can be found by reading the cell above the CustomPlayer code).

CustomEvalFn

• Edit the below to come up with your very own improved evaluation function. The typical rules about how you can and cannot edit the code we have given (namely, the function signature rules) apply here.
• IMPORTANT: There’s one big thing to keep in mind when the below is exported to submission.py. When the export happens, your resulting submission.py is parsed top-down, so you may have errors when trying to run that file with a custom evaluation function.
  • The fix is to make sure this does not happen is to follow these steps: Use “Edit->Move Cell Up” to move the below cell to just above the first time you call CustomEvalFn (probably in CustomPlayer) -> Now run helpers/notebook.ipynb -> Submit the resulting submission.py to Gradescope to test your submission.

Now you may need to change the move() method again in the CustomPlayer class. In addition, you may also need to edit eval_fn() in CustomPlayer to have your agent use the above custom evaluation function when it is playing against the test agents.

Section 2c Checkpoint

Now it’s a good time to submit for Section2c – See Exporting the notebook

In case you want to submit please uncomment and run the cell below.

Your code will be generated in the folder named section2c. Please upload submission.py file to Gradescope

Botfight (Optional, No Extra Credit)

In addition to the basic assignment, you will have the option to compete against your peers for the glory of being the Fall 2025 AI-Game-Playing champ. We’ll set up a system to pit your AI against others and we’ll post the top players to Ed. May the odds be ever in your favor.

Details on how to submit to the Botfight will be released on week 2 of the assignment.

Contribute to the class

If you find any typos and/or have some issues or suggestions on how to improve this or any future assignments, please feel free to make an Ed post.
